SD-X Sniper Evo Pro HSX Rear Hub Red

Compatible exclusively with Meybo HSX frames (Alloy & Carbon)!

The SD-X Sniper Evo Pro HSX Rear Hub is built for unlimited racing performance and designed specifically for Meybo HSX frames. This full-engagement rear hub combines lightweight aluminum construction with SKF ABEC-5 bearings to deliver uncompromising performance and reliability.

The direct engagement system ensures instant power transfer, silent operation, and zero resistance while freewheeling.

The hub is supplied exclusively as a 15 mm version and cannot be converted to a 10 mm bolt-on setup.

Features
- Supplied as standard in 15 mm configuration
- ISO-6 disc mount
- Available in 36-hole only
- Suitable for all racers
- High-quality SKF ABEC-5 bearings
- Hub shell and internals made from premium 7075 aluminum
- Available in a wide color range
- Hub supplied without EVO cog (must be ordered separately)
- Hub supplied without 15 mm axle

Technical Specifications
- Weight (36-hole): 428 g
- Wheel bearings: 2× 6903
- Clutch bearings: 2× Sniper Pro
- Driver outer bearing: 6806
- Driver inner bearing: 6705

A= Total length: 110mm
B= Distance flange to outside non-drive side: 25mm
C= Distance flange to outside drive side: 25mm
D= Flange diameter non-drive side: 56mm
E= Flange diameter drive side: 56mm

Spoke Calculator click here

More info:
- Exploding view
- Assembly and Disassembly video
- Sniper Evo Catalog
